Vayyl — Confidential Settlement Infrastructure for Stellar

Prove a settlement is valid without publishing the underlying amount, identity, or trading strategy.

Live Application • Architecture Specification • Demo Video • Transaction Evidence • Community & X • Feedback Form

Overview

Vayyl is a zero-knowledge confidential settlement protocol built natively for Stellar Soroban.

By leveraging native Soroban host functions introduced in Protocol 25 & 26 (CAP-0074 BN254 curve operations and CAP-0075 Poseidon2 permutations), Vayyl provides high-performance, cost-effective zero-knowledge settlement primitives. Users, institutions, and autonomous AI agents can execute confidential transfers, open shielded positions, and settle conditional escrows while verifying on-chain constraints at deterministic sub-cent costs.

🎥 Video Walkthrough & Demo

Watch the comprehensive video demonstration illustrating the full lifecycle of shielded deposits, private transfers with ephemeral-key ECDH discovery, unshielding with front-running protection, and on-chain verification on Stellar Soroban:

▶️ Click to Watch the Vayyl Protocol Demonstration on YouTube

📸 Protocol Interface Tour

1. Landing & Narrative Interface

The entry point introducing Vayyl's confidential settlement architecture, live empirical metrics, and protocol mechanisms.

2. Shielded Pool (Deposit, Transfer, Withdraw & Rage-Quit)

The core private payment interface. Generate client-side Groth16 proofs in Web Workers, transfer notes via ephemeral ECDH discovery, and unshield via relayers without revealing source commitments.

3. Private Positions & Leverage Attestation

Open and maintain leveraged positions with shielded collateral. Submit periodic zero-knowledge health attestations against Reflector SEP-40 oracle prices without revealing balance or position direction.

4. Conditional Orders & Sealed Escrow

Commit hidden limit orders and conditional escrows on-chain. Orders remain sealed until trigger condition proofs are submitted and executed.

5. Shielded Identity & Compliance Controls

Derive BabyJubjub shielded identities deterministically from Freighter wallet signatures. Manage encrypted note backups and check Association Set Provider (ASP) compliance status.

6. Protocol Analytics & Verification Dashboard

Real-time protocol transparency metrics displaying live contract states, verified on-chain executions, and cryptographic verifier activity.

📊 Traction & Empirical Verification

Vayyl is deployed and executing on Stellar Mainnet and Testnet. All metrics below are independently verifiable from on-chain contract addresses and public transaction ledgers.

Across both networks, Vayyl has executed 153 verified contract invocations across 18 deployed contracts. Every invocation maps to a named protocol capability rather than generic infrastructure filler.

Metric	Mainnet (Live since 11 July 2026)	Testnet (3 Deployment Generations)	Combined Total
Deployed Contracts	4 contracts	14 contracts	18 contracts
Verified Invocations	19 contract calls	134 contract calls	153 invocations
Active Test Wallets	1 wallet (bounded demo)	9 wallets (team test accounts)	10 wallets
Proving Mechanism	Native Soroban BN254 Groth16	Native Soroban BN254 Groth16	End-to-End ZK
Steady-State Deposit Fee	`~0.0144 XLM` (143,769 - 143,894 stroops)	Sub-cent testnet execution	Empirically measured
Steady-State Withdraw Fee	`0.0274 XLM` (274,053 stroops)	Sub-cent testnet execution	Deterministic cost

Mainnet Deployments & Proving Costs

Shielded Pool: CB2NWPFWW5YLD6UYWR4RFERECSMBF6SB62P7RRP2LF2P2EMDSDLAZ3OW
Groth16 / BN254 Verifier: CATKJ2WBLQXGNVMGZ6E4JEZVTRMVJO2SKA3H7VH53TVD2HJPSBQ46MRD
ASP Membership: CBJWADSNYX52I6GEASN5P7MS6NWQ4O5WWQJOPTNSKCRHYTK2BYET6YB3
ASP Non-Membership: CBJSFSZOEOEBSBTUZPTFZNAMP37PU7GKVFRERYSBTMYY7KPG6QKMAAQE

Ecosystem Cost Benchmark: Vayyl delivers the first published empirical costs of Groth16 verification on Stellar Mainnet. Compared to optimized Noir UltraHonk verification on Soroban (~0.09 XLM), Vayyl's BN254 Groth16 verification costs are 3x to 6x lower.

8 Protocol Capabilities Executed End-to-End On-Chain

Shielded Deposit: 15 testnet executions + 7 mainnet executions (22 total).
Private Shielded-to-Shielded Transfer: Ephemeral-key ECDH recipient discovery without publishing ciphertexts.
Unshield to Arbitrary Recipient: Relayer-submitted with zero user address linkage and front-running defeat.
ASP Compliance Enrollment: Merkle-tree membership insertion and in-circuit proof verification.
Private Position Open: Zero-knowledge margin commitment without revealing size or direction.
Private Health Attestation: In-circuit proof against Reflector SEP-40 oracle feeds.
Completed Two-Phase Liquidation: initiate_liquidation followed by reveal_and_seize.
Hidden Conditional Order & Agentic Settlement: Sealed order committed, proved, and settled; agentic settlement quest authorized and paid out.

Independent Verification Ledger: Google Drive Evidence Folder — Complete logs of all 153 transactions with transaction hashes, contract addresses, function names, timestamps, and explorer links.

🏛️ System Architecture

Vayyl is structured as a six-layer modular settlement stack where each layer depends strictly on the layers beneath it.

┌──────────────────────────────────────────────────────────────────┐
│ L5  CLIENT        Browser DApp · Freighter · Web Worker proving  │
│                   IndexedDB note vault · encrypted note backup   │
├──────────────────────────────────────────────────────────────────┤
│ L4  SERVICES      Indexer · Relayer · Oracle adapter · Keeper    │
│                   Proof bridge (snarkjs JSON → Soroban binary)   │
├──────────────────────────────────────────────────────────────────┤
│ L3  APPLICATION   PositionManager · LiquidationEngine            │
│                   HiddenOrderRegistry · AgenticSettlementHub     │
├──────────────────────────────────────────────────────────────────┤
│ L2  CORE          VayylPool (per asset) · VayylPoolFactory       │
│                   ASPMembership · ASPNonMembership · Vault       │
├──────────────────────────────────────────────────────────────────┤
│ L1  VERIFICATION  Groth16Verifier — CircuitId → VerificationKey  │
│                   ONE registry, callable by any Soroban contract │
├──────────────────────────────────────────────────────────────────┤
│ L0  STELLAR HOST  bn254_g1_add · bn254_g1_mul                    │
│                   bn254_multi_pairing_check · Poseidon2          │
│                   Stellar Asset Contract · Reflector SEP-40      │
└──────────────────────────────────────────────────────────────────┘

System Context & Actor Flow

flowchart LR
  U["User / Business"] -->|Freighter signature| C["Vayyl DApp<br/>(Web Worker Prover)"]
  AG["AI Agent<br/>(x402 / MPP)"] --> FAC["Confidential<br/>x402 Facilitator"]
  INT["External Integrator<br/>(Lending / DEX)"] -->|Verify Proof| V

  C -->|Signed Proof| R["Relayer Service<br/>(Fee-bump, non-custodial)"]
  C -->|Merkle Paths| IX["Indexer Service<br/>(PostgreSQL)"]
  FAC --> R
  R -->|Submit Tx| P["VayylPool<br/>(Per Asset)"]
  P --> V["Groth16Verifier<br/>(CircuitId -> VK)"]
  V --> H["Soroban Host Primitives<br/>(CAP-0074 & CAP-0075)"]
  P --> SAC["Stellar Asset Contract"]
  PM["PositionManager"] --> V
  PM --> ORC["Reflector SEP-40 Oracle"]
  PM --> VAULT["Counterparty Vault"]
  KP["Keeper Service"] --> PM
  IX -.->|Event Stream| P

🔐 Cryptographic Foundation

1. Key Derivation & Note Primitive

Every payment, position, and order in Vayyl descends deterministically from a single Freighter wallet signature:

flowchart TD
  W["Freighter Wallet Signature<br/>(Deterministic Salt)"] --> VK["viewKey"]
  VK --> SK["spendKey = Poseidon2(viewKey, 1)<br/>(reduced mod l)"]
  SK --> PK["(pubX, pubY) = spendKey · Base8<br/>(BabyJubjub Point)"]
  PK --> ADDR["Shielded Address<br/>(VAYYL… + CRC16)"]
  PK --> ASP["ASP Leaf = Poseidon2(pubX, pubY)"]
  PK --> CM["Commitment = Poseidon2(pubX, pubY, amount, blindness)"]
  CM --> NF["Nullifier = Poseidon2(commitment, spendKey)"]
  VK -. Future .-> IVK["Incoming Viewing Key (Auditor)"]
  VK -. Future .-> OVK["Outgoing Viewing Key (Auditor)"]
  VK -. Future .-> DK["Detection Key (FMD)"]

In-Circuit Public Key Derivation: (pubX, pubY) is strictly computed inside the circuit from spendKey using BabyJubjub scalar multiplication and never accepted as free prover input. This mathematically prevents arbitrary nullifier creation for a single note.
Range Checks & Subgroup Constraints: spendKey ∈ [1, l) where l ≈ 2^251.3 (the Base8 subgroup order) is strictly checked via Num2Bits(251) to eliminate alternative witness generation.

2. Private Payments & Ephemeral ECDH Discovery

sequenceDiagram
  autonumber
  participant S as Sender (Wallet A)
  participant P as VayylPool Contract
  participant IX as Indexer
  participant R as Recipient (Wallet B)
  participant RL as Relayer
  participant V as Groth16Verifier

  Note over S: 1. Generate ephemeral secret r<br/>Compute R = r · Base8<br/>Shared secret S = r · PK_recipient
  S->>S: blindness = Poseidon2(S.x, 0)
  S->>S: commitment = Poseidon2(pubX_b, pubY_b, amount, blindness)
  S->>S: Generate TransferV2 Proof (1-in / 1-out)
  S->>P: transfer_v2(proof, root, nullifier, commitment, R.x, R.y)
  P->>V: verify(TransferV2, proof, public_inputs)
  V-->>P: true
  P->>P: Mark nullifier spent & Insert new commitment
  P-->>IX: Emit TransferV2 Event {commitment, R.x, R.y}
  IX-->>R: Sync Event Stream
  Note over R: 2. Recipient scans events<br/>Compute S' = spendKey_b · R (= S)<br/>blindness = Poseidon2(S'.x, 0)
  R->>R: Match commitment -> Note detected!
  Note over R,RL: 3. Recipient unshields funds
  R->>R: withdraw_binding = Hash(recipient_addr, relayer_addr, fee)
  R->>R: Generate WithdrawV2 Proof (binding bound in-circuit)
  R->>RL: POST /v2/withdraw {proof, nullifier, binding}
  RL->>P: withdraw_v2(...) via Fee-Bump Tx
  P->>V: verify(WithdrawV2, proof)
  V-->>P: true
  P->>R: Transfer asset from SAC to recipient_addr

No Encrypted Ciphertexts On-Chain: Note transfer uses ephemeral Diffie-Hellman on BabyJubjub. The sender posts (R.x, R.y) as public inputs, and the recipient reconstructs the blindness secret locally.
Front-Running Immunity: In withdraw_v2, withdraw_binding cryptographically binds recipient, relayer, and fee. If an attacker intercepts the proof from the mempool and attempts to replace the recipient address, the on-chain verifier rejects the proof.

3. Note Lifecycle & Exit Paths

stateDiagram-v2
  [*] --> Unspent: deposit_v2 or transfer_v2 output
  Unspent --> SpentTransfer: transfer_v2 (1-in / 1-out)
  Unspent --> SpentWithdraw: withdraw_v2 (Relayed private exit)
  Unspent --> SpentRageQuit: ragequit_v2 (Public exit / compliance)
  Unspent --> LockedInPosition: position_open (Shielded margin)
  LockedInPosition --> Unspent: position_close (New note output)
  LockedInPosition --> Seized: Missed heartbeat + 2-phase liquidation
  SpentTransfer --> [*]
  SpentWithdraw --> [*]
  SpentRageQuit --> [*]
  Seized --> [*]

Rage-Quit Compliance Escape Hatch: If an Association Set Provider (ASP) delists an account after funds are shielded, the user can execute ragequit_v2. This publishes the deposit-to-payout link and recovers funds publicly without stranding capital. Both withdraw_v2 and ragequit_v2 consume the exact same nullifier.

🛠️ Repository Structure

Vayyl consists of four independent, decoupled toolchains:

Vayyl/
├── frontend/                 # Next.js 16 App Router + Client React DApp (/app)
│   ├── src/app/              # Marketing & Narrative landing page
│   ├── src/dapp/             # Shielded Pool, Positions, Escrow, Settings views
│   ├── src/lib/              # Prover, Web Worker bridge, note cryptography
│   └── public/circuits/      # Compiled WASM provers and final zkey artifacts
│
├── contracts/                # Rust Soroban Smart Contracts (no_std, wasm32)
│   ├── groth16-verifier/     # Centralized CircuitId -> VK verification engine
│   ├── vayyl-pool/           # Per-asset Merkle accumulator, deposit/transfer/withdraw
│   ├── vayyl-pool-factory/   # Multi-asset pool deployer
│   ├── asp-membership/       # Allowed set Merkle tree verifier
│   ├── asp-non-membership/   # Restricted set exclusion verifier
│   ├── position-manager/     # Private position open, health attestation, close
│   ├── liquidation-engine/   # 2-phase liquidation heartbeat & seize engine
│   ├── hidden-order-registry/# Sealed limit orders & trigger proof settlement
│   ├── agentic-settlement-hub/# AI agent x402 settlement & reward hub
│   └── vayyl-types/          # Shared cryptographic types & ABIs
│
├── circuits/                 # Circom 2.1 zero-knowledge circuits
│   ├── deposit_v2.circom     # Shielded deposit + ASP membership (2 inputs)
│   ├── transfer_v2.circom    # 1-in / 1-out private transfer (5 inputs)
│   ├── withdraw_v2.circom    # Unshield with front-running binding (3 inputs)
│   ├── ragequit_v2.circom    # Public exit escape hatch (3 inputs)
│   ├── position_open.circom  # Shielded position creation (4 inputs)
│   ├── position_health.circom# Oracle price attestation (4 inputs)
│   ├── position_close.circom # Position settlement (6 inputs)
│   └── lib/                  # Note, Poseidon2, BabyJubjub, Merkle primitives
│
├── backend/                  # Off-chain supporting services
│   ├── indexer/              # Real-time event indexer & Merkle tree DB (Node/TS)
│   ├── relayer/              # Non-custodial fee-bump transaction submitter
│   ├── keeper/               # Automated liquidation & order watcher
│   ├── oracle-adapter/       # SEP-40 Reflector price feed bridge
│   └── proof-bridge/         # Rust snarkjs JSON to Soroban binary translator
│
└── deployments/              # Deployment manifests and Merkle tree snapshots

⚡ Quickstart & Local Setup

Prerequisites

Node.js: v20+
Package Manager: pnpm (v9+)
Rust: nightly with wasm32-unknown-unknown target
Stellar CLI: stellar-cli v22+
Wallet: Freighter extension configured for Stellar Testnet

1. Run the Frontend DApp

# Navigate to frontend
cd frontend

# Install dependencies
pnpm install

# Configure testnet environment
cp .env.testnet .env.local

# Start Next.js Turbopack dev server
pnpm dev

Open http://localhost:3000 for the Protocol Landing Page.
Open http://localhost:3000/app?view=pool for the Shielded Pool DApp.

Note: Proof generation executes in a dedicated Web Worker to maintain UI responsiveness.

2. Run Local Indexer & Relayer

# Start Indexer (Terminal 1)
cd backend/indexer
pnpm install
pnpm dev

# Start Relayer (Terminal 2)
cd backend/relayer
pnpm install
pnpm dev

3. Verify Circuits & Merkle Trees

# Navigate to circuits
cd circuits

# Verify committed Merkle leaf tree snapshot against testnet pool
pnpm snapshot:verify

# Run circuit unit tests
pnpm test

4. Build and Test Soroban Contracts

# Run all contract unit tests (including real-proof verifications)
cargo test --workspace

# Build optimized WASM binaries
cargo build --workspace --target wasm32-unknown-unknown --release

🔒 Security Invariants & Honesty Boundaries

gamma != delta Verifier Enforcement: Groth16Verifier explicitly checks and rejects any verification key where $\gamma = \delta$. This structurally eliminates the vulnerability that compromised Veil Cash and FoomCash.
Poseidon V1 Ban: Poseidon V1 is strictly forbidden across all circuits and contracts due to the variable-length zero-padding collision vulnerability (CVE-2026-32129). Vayyl exclusively uses Poseidon2 permutations.
Phase-2 Trusted Setup Notice: The current Testnet and Mainnet demo proving keys were generated using a single-machine Phase-2 ceremony. Production mainnet deployments holding material user assets require an open, multi-party ceremony.
Testnet / Audit Status: Vault V1 is live on Mainnet as a bounded proof-of-concept. Contracts are under continuous testing and have not yet undergone external third-party security audits.

Feedback

We are collecting structured feedback from testers, integrators, and reviewers on the shielded pool, private positions, conditional orders, and the proving pipeline.

Submit feedback: Vayyl Feedback Form
Live responses: Feedback Response Sheet

Responses feed directly into the issue backlog. If you hit a proving failure, a stuck deposit, or an archived-note restore path, the form is the fastest route to getting it triaged.

📜 License

Licensed under either of:

Apache License, Version 2.0 (LICENSE-APACHE or http://www.apache.org/licenses/LICENSE-2.0)
MIT license (LICENSE-MIT or http://opensource.org/licenses/MIT)

at your option.

Built with ⚡ for the Stellar Soroban Ecosystem.

Name		Name	Last commit message	Last commit date
.codex		.codex
.impeccable		.impeccable
assets/screenshots		assets/screenshots
backend		backend
circuits		circuits
contracts		contracts
deployments		deployments
frontend		frontend
scripts		scripts
.gitignore		.gitignore
AGENT.md		AGENT.md
AGENTS.md		AGENTS.md
README.md		README.md
RELAYERS.md		RELAYERS.md
install_stellar.py		install_stellar.py
package.json		package.json
pnpm-lock.yaml		pnpm-lock.yaml
render.yaml		render.yaml
skills-lock.json		skills-lock.json

Navigation Menu

Repository files navigation

Vayyl — Confidential Settlement Infrastructure for Stellar

Overview

🎥 Video Walkthrough & Demo

📸 Protocol Interface Tour

1. Landing & Narrative Interface

2. Shielded Pool (Deposit, Transfer, Withdraw & Rage-Quit)

3. Private Positions & Leverage Attestation

4. Conditional Orders & Sealed Escrow

5. Shielded Identity & Compliance Controls

6. Protocol Analytics & Verification Dashboard

📊 Traction & Empirical Verification

Mainnet Deployments & Proving Costs

8 Protocol Capabilities Executed End-to-End On-Chain

🏛️ System Architecture

System Context & Actor Flow

🔐 Cryptographic Foundation

1. Key Derivation & Note Primitive

2. Private Payments & Ephemeral ECDH Discovery

3. Note Lifecycle & Exit Paths

🛠️ Repository Structure

⚡ Quickstart & Local Setup

Prerequisites

1. Run the Frontend DApp

2. Run Local Indexer & Relayer

3. Verify Circuits & Merkle Trees

4. Build and Test Soroban Contracts

🔒 Security Invariants & Honesty Boundaries

Feedback

📜 License

About

Releases

Packages

Contributors

Languages

Latest commit

History

Folders and files

Repository files navigation

Vayyl — Confidential Settlement Infrastructure for Stellar

Overview

🎥 Video Walkthrough & Demo

📸 Protocol Interface Tour

1. Landing & Narrative Interface

2. Shielded Pool (Deposit, Transfer, Withdraw & Rage-Quit)

3. Private Positions & Leverage Attestation

4. Conditional Orders & Sealed Escrow

5. Shielded Identity & Compliance Controls

6. Protocol Analytics & Verification Dashboard

📊 Traction & Empirical Verification

Mainnet Deployments & Proving Costs

8 Protocol Capabilities Executed End-to-End On-Chain

🏛️ System Architecture

System Context & Actor Flow

🔐 Cryptographic Foundation

1. Key Derivation & Note Primitive

2. Private Payments & Ephemeral ECDH Discovery

3. Note Lifecycle & Exit Paths

🛠️ Repository Structure

⚡ Quickstart & Local Setup

Prerequisites

1. Run the Frontend DApp

2. Run Local Indexer & Relayer

3. Verify Circuits & Merkle Trees

4. Build and Test Soroban Contracts

🔒 Security Invariants & Honesty Boundaries

Feedback

📜 License

About

Topics

Resources

Stars

Watchers

Forks

Releases

Packages

Contributors

Languages
