🏅 Sports Team Manager

Assignment 10.3 – WPF Desktop App • EF Core • SQL Server LocalDB • MSSA Project

---

🎥 Demo Video (Coming Soon)

A full video demonstration will be added here.

---

📖 Project Summary

Sports Team Manager is a WPF desktop application that manages sports teams with full CRUD functionality.
The focus of this assignment is on backend skills: C#, Entity Framework Core, SQL Server LocalDB, database migrations, and basic querying, with a simple WPF UI on top.

This project is part of Assignment 10.3 – SportsTeamManager (WPF) in the MSSA Cloud Application Development program.

---

⭐ Core Features

• Full CRUD operations for sports teams
• DataGrid bound directly to EF Core query results
• ComboBox for selecting a sport
• SQL Server LocalDB handled through EF Core
• Database migrations to evolve the schema safely
• Built‑in search by team name, city, or sport
• Automatic team count display in the UI

💡 Seed Data:
On first run, the app automatically seeds three Chicago teams into the database:

• Chicago Bulls (Basketball)
• Chicago Bears (Football)
• Chicago Cubs (Baseball)

---

🔄 App Workflow (High Level)

flowchart TD
    A[User launches WPF app] --> B[MainWindow checks for seed data]
    B --> C[Seed default Chicago teams if database is empty]
    C --> D[Load all SportsTeams into DataGrid]
    D --> E[User adds / updates / deletes a team]
    E --> F[EF Core SaveChanges to SQL Server LocalDB]
    F --> G[Reload teams + update team count]
    D --> H[User types in Search box]
    H --> I[LINQ filter over SportsTeams table]
    I --> G

Loading

---

🧱 Tech Stack

• Language: C#
• Framework: .NET (WPF)
• UI: WPF (XAML + code-behind)
• ORM: Entity Framework Core
• Database: SQL Server LocalDB ((localdb)\MSSQLLocalDB)
• Other: LINQ, EF Core migrations, basic data binding

WPF is used as a front-end shell, while most of the learning is around EF Core, migrations, and backend logic.

---

🗂️ Folder Structure

SportsTeamManager/
├── SportsTeamManager.sln
├── README.md
├── .gitignore
└── SportsTeamManager/
    ├── App.xaml
    ├── App.xaml.cs
    ├── MainWindow.xaml
    ├── MainWindow.xaml.cs          // event handlers + CRUD + search
    ├── Data/
    │   ├── AppDbContext.cs         // EF Core DbContext
    │   └── Migrations/             // EF Core migration files + snapshot
    ├── Models/
    │   └── SportsTeam.cs           // entity model for EF Core
    └── Properties/                 // WPF app metadata

Update folder names if your solution is organized slightly differently.

---

🧩 Architecture Overview

flowchart LR
    UI["WPF UI<br/>(MainWindow + controls)"] --> B["Code-behind<br/>(event handlers)"]
    B --> C["EF Core<br/>(AppDbContext)"]
    C --> D["SQL Server LocalDB<br/>SportsTeamDB"]

Loading

• The WPF UI (XAML + code-behind) handles buttons, text boxes, DataGrid, ComboBox, and search input.
• The code-behind calls AppDbContext to query and save SportsTeam records.
• EF Core maps the SportsTeam model to the SportsTeamDB LocalDB database using migrations.

---

🗃️ Database Model Example

AppDbContext

using Microsoft.EntityFrameworkCore;
using SportsTeamManager.Models;

namespace SportsTeamManager.Data
{
    public class AppDbContext : DbContext
    {
        public DbSet<SportsTeam> SportsTeams => Set<SportsTeam>();

        protected override void OnConfiguring(DbContextOptionsBuilder optionsBuilder)
        {
            optionsBuilder.UseSqlServer(
                "Server=(localdb)\\MSSQLLocalDB;Database=SportsTeamDB;Trusted_Connection=True;");
        }
    }
}

SportsTeam Entity

using System.ComponentModel.DataAnnotations;

namespace SportsTeamManager.Models
{
    public class SportsTeam
    {
        [Key]
        public int TeamId { get; set; }
        public string? Name { get; set; }
        public string? City { get; set; }
        public string? Sport { get; set; }
        public int FoundedYear { get; set; }
        public int ChampionshipsWon { get; set; }
    }
}

EF Core maps this class into a SportsTeams table with TeamId as the identity primary key, plus the additional fields for team metadata.

---

💻 Sample CRUD and Search Logic (MainWindow.xaml.cs)

Seeding Data and Initial Load

public partial class MainWindow : Window
{
    private readonly AppDbContext _context = new AppDbContext();

    public MainWindow()
    {
        InitializeComponent();

        // Seed default Chicago teams if database is empty
        if (!_context.SportsTeams.Any())
        {
            _context.SportsTeams.Add(new SportsTeam
            {
                Name = "Chicago Bulls",
                City = "Chicago",
                Sport = "Basketball",
                FoundedYear = 1966,
                ChampionshipsWon = 6
            });

            _context.SportsTeams.Add(new SportsTeam
            {
                Name = "Chicago Bears",
                City = "Chicago",
                Sport = "Football",
                FoundedYear = 1919,
                ChampionshipsWon = 1
            });

            _context.SportsTeams.Add(new SportsTeam
            {
                Name = "Chicago Cubs",
                City = "Chicago",
                Sport = "Baseball",
                FoundedYear = 1876,
                ChampionshipsWon = 3
            });

            _context.SaveChanges();
        }

        LoadTeams();

        UpdateButton.IsEnabled = false;
        DeleteButton.IsEnabled = false;
    }

    private void LoadTeams()
    {
        var teams = _context.SportsTeams.ToList();
        TeamsDataGrid.ItemsSource = teams;
        TeamCountTextBlock.Text = $"Total Teams: {teams.Count}";
    }
}

Validation Helper

private bool ValidateInputs()
{
    if (string.IsNullOrWhiteSpace(NameTextBox.Text) ||
        string.IsNullOrWhiteSpace(CityTextBox.Text) ||
        SportComboBox.SelectedItem == null)
    {
        MessageBox.Show("Name, City, and Sport are required.");
        return false;
    }

    if (!int.TryParse(FoundedYearTextBox.Text, out _) ||
        !int.TryParse(ChampionshipsTextBox.Text, out _))
    {
        MessageBox.Show("Founded Year and Championships must be numbers.");
        return false;
    }

    return true;
}

Create (Add)

private void AddButton_Click(object sender, RoutedEventArgs e)
{
    if (!ValidateInputs()) return;

    var team = new SportsTeam
    {
        Name = NameTextBox.Text,
        City = CityTextBox.Text,
        Sport = (SportComboBox.SelectedItem as ComboBoxItem)?.Content.ToString(),
        FoundedYear = int.Parse(FoundedYearTextBox.Text),
        ChampionshipsWon = int.Parse(ChampionshipsTextBox.Text)
    };

    _context.SportsTeams.Add(team);
    _context.SaveChanges();
    LoadTeams();
    ClearInputs();
}

Update

private void UpdateButton_Click(object sender, RoutedEventArgs e)
{
    if (TeamsDataGrid.SelectedItem is not SportsTeam selected) return;
    if (!ValidateInputs()) return;

    selected.Name = NameTextBox.Text;
    selected.City = CityTextBox.Text;
    selected.Sport = (SportComboBox.SelectedItem as ComboBoxItem)?.Content.ToString();
    selected.FoundedYear = int.Parse(FoundedYearTextBox.Text);
    selected.ChampionshipsWon = int.Parse(ChampionshipsTextBox.Text);

    _context.SaveChanges();
    LoadTeams();
}

Delete

private void DeleteButton_Click(object sender, RoutedEventArgs e)
{
    if (TeamsDataGrid.SelectedItem is not SportsTeam selected) return;

    var result = MessageBox.Show(
        $"Are you sure you want to delete '{selected.Name}'?",
        "Confirm Delete",
        MessageBoxButton.YesNo,
        MessageBoxImage.Warning);

    if (result == MessageBoxResult.Yes)
    {
        _context.SportsTeams.Remove(selected);
        _context.SaveChanges();
        LoadTeams();
        ClearInputs();
    }
}

Selection Handling and Clear

private void TeamsDataGrid_SelectionChanged(object sender, SelectionChangedEventArgs e)
{
    if (TeamsDataGrid.SelectedItem is SportsTeam selected)
    {
        NameTextBox.Text = selected.Name;
        CityTextBox.Text = selected.City;

        SportComboBox.SelectedItem = SportComboBox.Items
            .Cast<ComboBoxItem>()
            .FirstOrDefault(i => i.Content.ToString() == selected.Sport);

        FoundedYearTextBox.Text = selected.FoundedYear.ToString();
        ChampionshipsTextBox.Text = selected.ChampionshipsWon.ToString();

        UpdateButton.IsEnabled = true;
        DeleteButton.IsEnabled = true;
    }
    else
    {
        UpdateButton.IsEnabled = false;
        DeleteButton.IsEnabled = false;
    }
}

private void ClearButton_Click(object sender, RoutedEventArgs e)
{
    ClearInputs();
    TeamsDataGrid.UnselectAll();
}

private void ClearInputs()
{
    NameTextBox.Text = "";
    CityTextBox.Text = "";
    SportComboBox.SelectedItem = null;
    FoundedYearTextBox.Text = "";
    ChampionshipsTextBox.Text = "";
}

Search (Live Filter)

private void SearchTextBox_TextChanged(object sender, TextChangedEventArgs e)
{
    string search = SearchTextBox.Text.ToLower();

    var filtered = _context.SportsTeams
        .Where(t =>
            t.Name.ToLower().Contains(search) ||
            t.City.ToLower().Contains(search) ||
            t.Sport.ToLower().Contains(search))
        .ToList();

    TeamsDataGrid.ItemsSource = filtered;
    TeamCountTextBlock.Text = $"Total Teams: {filtered.Count}";
}

---

🚀 How to Run

1. Clone the repository.
2. Open the solution in Visual Studio: SportsTeamManager.sln.
3. Restore NuGet packages for EF Core and the SQL Server provider.
4. From Package Manager Console, run:
   • Update-Database
5. Set SportsTeamManager as the Startup Project.
6. Press F5 or Ctrl + F5 to run the application.

On first run, the app seeds three Chicago teams into the LocalDB database if it is empty.

---

📌 Future Improvements

• Add a Player entity and relate it to SportsTeam (one-to-many)
• Add a small Web API layer on top of this EF Core backend
• Move logic from code-behind into a more MVVM-style structure
• Add validation summaries and more robust error handling
• Implement stats dashboards and additional filtering/sorting with LINQ

---
