Canodades is the new statistics app for Canòdrom employees. Its name comes from catalan Les dades del Canòdrom, meaning The Canòdrom's data.
This app allows filtering and sorting from a list of events that took place in the Canòdrom. Certain data can also be showed graphically.
Data collected and displayed include but do not limit to:
- Event name.
- Attendees.
- Attendees by gender.
- Event type.
- Where did the attendees find out about the event.
Each name is linked to its respective GitHub account.
Backend:
- NestJS.
- MySQL.
- MomentJS.
Frontend:
- React with Typescript.
- Tailwind.
- Shadcn.
- ECharts.
Common tools:
- VSCode.
The platform is deployed, meaning that clicking here will lead you its website, allowing you to make use of the app.
If you prefer to use it locally, you can download this GitHub repository, by using Git Clone or downloading the compressed .zip repository, then you will need to have npm or pnpm installed. If you already have pnpm installed you may skip to Dependencies installation step.
To install pnpm on Windows systems, you may run the following code:
iwr https://get.pnpm.io/install.ps1 -useb | iex
On Linux/MacOS systems:
wget -qO- https://get.pnpm.io/install.sh | sh -
Once pnpm installed, dependencies must be installed before running the app for the first time. This step is installation related, and will not be necessary to excecute in the future.
In order to do so, two terminals must be opened. One pointing to the client folder, and another one pointing to the server folder. Usually this can be done by opening the folder, right clicking on an empty space in the folder and clicking Open terminal. In both terminals, the following command must be run:
pnpm install
Once depencencies are installed, you will need to run both the backend and frontend of the app. For this step, we will also need two terminals, one pointing to the client folder and another one pointing to the server folder. If you have just installed dependencies, these terminals will work. If not, you will need to open them again.
In the server terminal, run:
pnpm start
In the client terminal, run:
pnpm run dev
Then, visiting http://localhost:5173/ in your web browser will display the app's graphic interface.
The app's database is cloud hosted, so there is no need to download it nor install it.
For the time being, the app is only available in Catalan.
A first glimpse of the app shows a dashboard containing empty graphics and an empty data table, the latter resembling a spreadsheet.
This data table is the app's core. Clicking Filtre per data (Filter by date) will load events using the chosen date filters. You may test the app by clicking the Sel·lecció (Select) dropdown and choosing Todos los eventos (all events). This action will activate the graphics with the data being shown in the table.
You may also use the rest of the filters such as, Cerca títol (Search by title), Cerca temàtica (Search by theme), Cerca tipus d'activitat (Search by event type) and search by date range.
Clicking a specific event will only prompt data related to this event. This will result in the Temàtica (Theme) and Tipus d'activitat (Event type) graphics not changing, given that these are global statistics and not individual.
A Form is also available to manually enter data from events. This data will be stored in the app's database, making it automatically available in the data table, and therefore, part of the statistics.
The Descarrega (Download) button will download the events information in .XSLX format.
The Carrega (Upload) allows .XSLX and .CSV files to be uploaded and included to the app's database. Please note that these files must follow the data table structure. In future versions of the app, import of Decidim's meetings .CSV might be implemented.
