stable-diffusion.cpp

stable-diffusion.cpp for Qualcomm devices

This branch provides optimized stable-diffusion.cpp and GGML paths for Qualcomm Hexagon NPUs and Adreno GPUs. It is used by Local Dream for on-device DiT inference.

Important News

Date Update
2026-09-17 Added Hexagon NPU support for Z-Image Turbo and FLUX.2/Klein 4B.
2026-09-20 Added Hexagon NPU support for FLUX.2/Klein 9B Q4_0.

Hexagon NPU

Weights

Performance

Device: Snapdragon 8 Elite, SM8750, HTP v79. Text encoder, DiT, and VAE run on HTP. Prompt: a lovely cat. Sampler: Euler. CFG: 1. Seed: 42. E2E includes text encoding, all sampling steps, and VAE decoding.

Model Resolution Steps Upstream Q4_0 DiT FP8 DiT VAE E2E
Z-Image Turbo 1024x1024 8 91.03 s/it 10.26 s/it 2.47 s 100.54 s
FLUX.2/Klein 4B 1024x1024 4 79.42 s/it 8.54 s/it 2.14 s 49.89 s
Z-Image Turbo 1536x1536 8 OOM 32.91 s/it 9.08 s 306.03 s
FLUX.2/Klein 4B 1536x1536 4 OOM 22.42 s/it 5.44 s 111.68 s
Z-Image Turbo 2048x2048 4 OOM 72.51 s/it 14.24 s 307.07 s
FLUX.2/Klein 4B 2048x2048 4 OOM 46.24 s/it 19.28 s 210.77 s

The 1024 and 1536 runs use direct VAE decode. The 2048 runs use 64x64 VAE tiles. At 1K, FP8 is 8.87x faster for Z-Image and 9.30x faster for FLUX.2/Klein than the current upstream Hexagon Q4_0/Q8_0 path.

Images

Z-Image Turbo FLUX.2/Klein 4B
1024x1024, 8 steps
Z-Image 1024x1024, 8 steps		 1024x1024, 4 steps
FLUX.2 Klein 1024x1024, 4 steps
1536x1536, 8 steps
Z-Image 1536x1536, 8 steps		 1536x1536, 4 steps
FLUX.2 Klein 1536x1536, 4 steps
2048x2048, 4 steps
Z-Image 2048x2048, 4 steps		 2048x2048, 4 steps
FLUX.2 Klein 2048x2048, 4 steps

FLUX.2/Klein 9B

Klein 9B uses Q4_0 DiT and Q4_0 Qwen3-8B weights. Text encoder parameters are released after conditioning with te=disk; DiT, text encoding, and VAE execution all run on HTP.

Resolution Steps Warm DiT VAE decode E2E
1024x1024 4 15.52 s/it 2.25 s 77.76 s

FLUX.2 Klein 9B Q4_0, 1024x1024, 4 steps

./sd-cli \
  --diffusion-model flux-2-klein-9b-Q4_0.gguf \
  --llm Qwen3-8B-Q4_0.gguf \
  --vae flux2-vae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --params-backend te=disk \
  --fa --vae-conv-direct \
  -t 4 \
  -p 'A cinematic photograph of a red fox standing on a moss-covered stone bridge in an autumn forest, golden morning light, mist between the trees, highly detailed fur, natural colors' \
  --cfg-scale 1 --steps 4 --sampling-method euler \
  -W 1024 -H 1024 --seed 42 \
  -o klein9b_q40_segmented_1024_s4.png

Commands

Place sd-cli, libggml-htp-v79.so, the model files, and the VAE files in the current directory, then run:

export LD_LIBRARY_PATH="$PWD" ADSP_LIBRARY_PATH="$PWD"

Z-Image Turbo, 1024x1024, 8 steps

./sd-cli \
  --diffusion-model z-image-turbo_fp8_scaled_e4m3fn_KJ.safetensors \
  --llm llm.gguf \
  --vae ae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --fa --vae-conv-direct \
  -t 4 -p "a lovely cat" --cfg-scale 1 \
  --steps 8 --sampling-method euler \
  -W 1024 -H 1024 --seed 42 \
  -o zimage_1024_s8.png

FLUX.2/Klein 4B, 1024x1024, 4 steps

./sd-cli \
  --diffusion-model flux-2-klein-4b-fp8.safetensors \
  --llm llm.gguf \
  --vae flux2-vae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --fa --vae-conv-direct \
  -t 8 -p "a lovely cat" --cfg-scale 1 \
  --steps 4 --sampling-method euler \
  -W 1024 -H 1024 --seed 42 \
  -o klein_1024_s4.png

Z-Image Turbo, 1536x1536, 8 steps

./sd-cli \
  --diffusion-model z-image-turbo_fp8_scaled_e4m3fn_KJ.safetensors \
  --llm llm.gguf \
  --vae ae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --fa --vae-conv-direct \
  -t 8 -p "a lovely cat" --cfg-scale 1 \
  --steps 8 --sampling-method euler \
  -W 1536 -H 1536 --seed 42 \
  -o zimage_1536_s8.png

FLUX.2/Klein 4B, 1536x1536, 4 steps

./sd-cli \
  --diffusion-model flux-2-klein-4b-fp8.safetensors \
  --llm llm.gguf \
  --vae flux2-vae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --fa --vae-conv-direct \
  -t 8 -p "a lovely cat" --cfg-scale 1 \
  --steps 4 --sampling-method euler \
  -W 1536 -H 1536 --seed 42 \
  -o klein_1536_s4.png

Z-Image Turbo, 2048x2048, 4 steps

./sd-cli \
  --diffusion-model z-image-turbo_fp8_scaled_e4m3fn_KJ.safetensors \
  --llm llm.gguf \
  --vae ae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --params-backend te=disk \
  --fa --vae-conv-direct \
  --vae-tiling --vae-tile-size 64x64 --vae-tile-overlap 0.25 \
  -t 4 -p "a lovely cat" --cfg-scale 1 \
  --steps 4 --sampling-method euler \
  -W 2048 -H 2048 --seed 42 \
  -o zimage_2048_s4.png

FLUX.2/Klein 4B, 2048x2048, 4 steps

./sd-cli \
  --diffusion-model flux-2-klein-4b-fp8.safetensors \
  --llm llm.gguf \
  --vae flux2-vae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --fa --vae-conv-direct \
  --vae-tiling --vae-tile-size 64x64 --vae-tile-overlap 0.25 \
  -t 4 -p "a lovely cat" --cfg-scale 1 \
  --steps 4 --sampling-method euler \
  -W 2048 -H 2048 --seed 42 \
  -o klein_2048_s4.png

FP8 versus upstream Q4_0/Q8_0

Resolution: 1024x1024. Sampling steps: 8.

雨夜的未来上海外滩，镜头前是一辆旧式有轨电车穿过积水街道，街边霓虹牌同时写着“欢迎光临”“火锅”“Open 24 Hours”，远处玻璃摩天楼与石库门老建筑并列，空中漂浮无人机广告屏，屏幕上有清晰汉字“春风得意”，画面里有穿风衣的人群、红色雨伞、湿漉漉的柏油路反射青蓝与橙红灯光，构图复杂、层次深、电影感、超细节

Upstream Q4_0 + Q8_0 F8_E4M3
Z-Image Q4_0 plus Q8_0 Z-Image F8_E4M3

Image editing

Z-Image Turbo generates the reference image, then FLUX.2/Klein removes the Einstein field equation while preserving the rest of the scene.

Z-Image Turbo reference FLUX.2/Klein edit
1024x1024, 8 steps
Einstein teaching in front of a blackboard		 1024x1024, 4 steps
Einstein field equation removed from the blackboard

Generate the reference with Z-Image Turbo

./sd-cli \
  --diffusion-model z-image-turbo_fp8_scaled_e4m3fn_KJ.safetensors \
  --llm llm.gguf \
  --vae ae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --fa --vae-conv-direct \
  -t 4 \
  -p "爱因斯坦站在黑板前教学，身前是有SJTU标志的讲台桌，手持粉笔。黑板上清晰写着爱因斯坦场方程：G_μν + Λg_μν = 8πG T_μν；以及麦克斯韦方程微分形式：dF = 0，d*F = *J。写实风格，大学课堂，学术氛围。" \
  --cfg-scale 1 --steps 8 --sampling-method euler \
  -W 1024 -H 1024 --seed 42 \
  -o zimage_einstein_1024_s8.png

Edit with FLUX.2/Klein

./sd-cli \
  --diffusion-model flux-2-klein-4b-fp8.safetensors \
  --llm llm.gguf \
  --vae flux2-vae.safetensors \
  --backend diffusion=HTP0,te=HTP0,vae=HTP0 \
  --fa --vae-conv-direct \
  -t 4 \
  -p "删除黑板上的爱因斯坦场方程‘G_μν + Λg_μν = 8πG T_μν’，将该公式擦除干净并自然补全黑板背景。保留麦克斯韦方程‘dF = 0，d*F = *J’、爱因斯坦、带SJTU标志的讲台桌、粉笔、大学课堂和其他画面内容不变，保持写实风格。" \
  --ref-image zimage_einstein_1024_s8.png \
  --cfg-scale 1 --steps 4 --sampling-method euler \
  -W 1024 -H 1024 --seed 42 \
  -o klein_edit_remove_equation_1024_s4.png

Adreno GPU

Model Size / steps Before s/it After s/it Before sampling (s) After sampling (s)
Klein 4B 512 / 4 11.81 5.45 52.76 25.54
Klein 4B 1024 / 4 37.65 21.15 154.09 90.84
Z-Image Turbo 512 / 8 12.65 6.88 107.48 60.59
Z-Image Turbo 1024 / 8 65.03 36.27 505.22 292.91

Images

Case Before After
Klein 512, 4 steps Klein 512 before Klein 512 after
Klein 1024, 4 steps Klein 1024 before Klein 1024 after
Z-Image 512, 8 steps Z-Image 512 before Z-Image 512 after
Z-Image 1024, 8 steps Z-Image 1024 before Z-Image 1024 after

Model weights

The GGUF weights can be converted with stable-diffusion.cpp or downloaded directly from Flux.2 Klein Adreno and Z-Image Turbo Adreno.

Commands

Build with GGML_OPENCL_USE_ADRENO_KERNELS=ON.

export GGML_OPENCL_Q4_0_DENSE_DP4A=1
export GGML_OPENCL_XMEM_SDPA=1

Klein 512

./sd-cli --diffusion-model models/flux-2-klein-4b-Q4_0.gguf --llm models/qwen_3_4b-Q4_0.gguf --vae models/flux2-vae.safetensors -p 'a lovely cat' --cfg-scale 1 --guidance 3.5 --steps 4 --seed 42 -W 512 -H 512 --diffusion-fa --vae-conv-direct -t 4 -v -o klein_512.png

Klein 1024

./sd-cli --diffusion-model models/flux-2-klein-4b-Q4_0.gguf --llm models/qwen_3_4b-Q4_0.gguf --vae models/flux2-vae.safetensors -p 'a lovely cat' --cfg-scale 1 --guidance 3.5 --steps 4 --seed 42 -W 1024 -H 1024 --diffusion-fa --vae-conv-direct -t 4 -v -o klein_1024.png

Z-Image 512

./sd-cli --diffusion-model models/z_image_turbo-Q4_0-nobf16.gguf --llm models/qwen_3_4b-Q4_0.gguf --vae models/ae_old.safetensors -p 'a lovely cat wearing black sunglasses, studio photo' --cfg-scale 1 --guidance 3.5 --steps 8 --seed 42 -W 512 -H 512 --diffusion-fa --vae-conv-direct -t 4 -v -o zimage_512.png

Z-Image 1024

./sd-cli --diffusion-model models/z_image_turbo-Q4_0-nobf16.gguf --llm models/qwen_3_4b-Q4_0.gguf --vae models/ae_old.safetensors -p 'a lovely cat wearing black sunglasses, studio photo' --cfg-scale 1 --guidance 3.5 --steps 8 --seed 42 -W 1024 -H 1024 --diffusion-fa --vae-conv-direct -t 4 -v -o zimage_1024.png
