A recovery plane for ROS 2 robots: detect a fault, decide what to do about it, gate the actuation that follows. Validated across eight bounded hardware sessions on a live Unitree GO2 with a Jetson Orin NX companion computer.
Most ROS 2 stacks have no single place that owns "a fault happened, now what."
Diagnostics get reported, watchdogs catch dead nodes, navigation has its own
recovery behaviors, and a mux arbitrates whose /cmd_vel wins, but nothing
closes the loop from detection through a policy decision to a gated actuation
as one system with one safety envelope. HELIX is that loop: four ROS 2
lifecycle tiers, SENSE to CONTEXT to DIAGNOSE to RECOVER, where RECOVER is the
only publisher of /helix/cmd_vel and is gated by an enable flag, a 5 s
per-fault cooldown, and an action allowlist. It has been run end to end on a
live GO2 across eight lab sessions, most recently a 439 s idle run that
produced 30 detected faults, 14 recovery hints, 14 audited recovery actions,
and 3,064 zero-twist commands. docs/comparison.md is
the honest version of this paragraph: it compares HELIX against
diagnostic_updater, software_watchdogs, system_modes, Nav2 recovery, and
twist_mux, and says plainly where HELIX duplicates each one.
- Proven: the closed loop runs end to end on a live GO2. A fault enters at
SENSE, a rule in DIAGNOSE (R1 to R4) turns it into a
RecoveryHint, and RECOVER emits an audited, allowlisted, cooldown-gated action. Session 8 reproduced this 14 times with no allowlist or cooldown violation. - Not proven: physical stopping.
/helix/cmd_velhad zero downstream subscribers during Session 8, so STOP_AND_HOLD is a real, audited decision that lands on a topic nothing is listening to. It has not yet been wired through atwist_muxfallback to the motors. "The robot holds" is proven through the software path only. - Found and fixed, not assumed away: the CONTEXT tier's
ContextBuffercrashed roughly one second after activation in every prior session, including hardware, on anrclpydetail (DiagnosticStatus.levelarrives as a one-bytebytesobject;int()on it raisesValueError). This means no earlier session result should be read as having had a live context snapshot behind it. The fix is a two-line type check (src/helix_diagnosis/helix_diagnosis/context_buffer.py), covered by tests that pin both thebytesandintforms. - Named plainly, not buried: on an idle, stationary GO2, Session 8 produced 9 STOP_AND_HOLD events in seven minutes. That is the false-positive rate a robotics engineer should assume until the detector work below lands in the shipped config.
dashboard/ is a single-file, self-contained HTML console
(dashboard/helix_console.html, no server, no build step, no network) that
replays the Session 8 telemetry tier by tier: a fault ticks in on SENSE, the
rule engine's decision appears at DIAGNOSE, and the resulting zero-twist
command stream plays out at RECOVER, alongside the two STOP_AND_HOLD windows
and the cooldown timer that produced them. Every number on the page is read
out of dashboard/assets/events.json and rate.json, extracted from the
Session 8 bag, not hand-written. It also shows a bug rather than hiding it:
three RESUMEs in that run were rejected as SUPPRESSED_COOLDOWN because a
RESUME was checked against the cooldown of the STOP it was trying to clear.
That bag predates the fix; RESUME is now exempt from cooldown. Open it locally:
git clone https://github.com/yusufdxb/helix.git
open helix/dashboard/helix_console.html # or double-click itDetails and data provenance: dashboard/README.md.
The most interesting result in this repo is not that the closed loop works,
it is what analysis/ found when it finally measured the shipped
anomaly detector instead of tuning it by feel. At zscore_threshold: 4.0,
window_size: 60 (the shipped config), replaying 62 synthetic fault
injections onto real idle GO2 telemetry:
| Fault model | Shipped (thr 4.0, W 60) | Proposed (thr 3.5, W 120) |
|---|---|---|
| Topic death | 62 / 62 | 62 / 62 |
| 10-sigma sustained step | 1 / 62 | 60 / 62 |
| 50 percent rate collapse | 0 / 62 | 62 / 62 |
Both operating points measure 0.0 false alarms per hour on 901.5 s of real
idle telemetry, and both hold the same 2.5 s median detection latency. The
mechanism is self-masking: the z-score is scored against a rolling window that
the sustained fault itself is filling, so the score decays back below
threshold at roughly the same instant min_anomaly_duration_s first permits
an emission to fire. window_size was the parameter that controlled this and
it had never been swept before this analysis.
This is a measurement, not a shipped change: the deployed config is
deliberately unchanged pending hardware confirmation. Read
analysis/README.md before quoting any number above.
It states, among other caveats, that these idle baselines are roughly 6x
quieter than Session 8 actually was (so the false-alarm figures are a lower
bound) and that rate_hz/utlidar_robot_odom, the metric responsible for 5 of
Session 8's 9 real stops, is absent from every idle capture on hand.
graph LR
GRAPH(["monitored ROS 2 graph"])
SENSE["<b>SENSE</b><br/>helix_core<br/>helix_sensing_cpp (port)<br/>helix_adapter"]
DIAGNOSE["<b>DIAGNOSE</b><br/>helix_diagnosis<br/>(rules R1-R4)"]
RECOVER["<b>RECOVER</b><br/>helix_recovery<br/>(allowlist +<br/>safety env.)"]
EXPLAIN["<b>EXPLAIN</b><br/>helix_explanation<br/>(local LLM,<br/>advisory)"]
CMDVEL(["/cmd_vel + lifecycle"])
GRAPH --> SENSE
SENSE -- "/helix/faults" --> DIAGNOSE
DIAGNOSE -- "/helix/recovery_hints" --> RECOVER
RECOVER --> CMDVEL
SENSE -- "/helix/faults" --> EXPLAIN
classDef tier fill:#1f2937,stroke:#60a5fa,stroke-width:2px,color:#f9fafb;
classDef io fill:#374151,stroke:#9ca3af,color:#f9fafb;
class SENSE,DIAGNOSE,RECOVER,EXPLAIN tier;
class GRAPH,CMDVEL io;
Full detail: ARCHITECTURE.md. Design notes for the C++ port:
docs/CPP_PORT_DESIGN_ANOMALY_DETECTOR.md.
mkdir -p ~/helix_ws/src
cd ~/helix_ws/src
git clone https://github.com/yusufdxb/helix.git
cd ~/helix_ws
source /opt/ros/humble/setup.bash
colcon build --symlink-install
source install/setup.bash# launch the sensing stack
ros2 launch helix_bringup helix_sensing.launch.py
# inject faults (separate terminal)
ros2 run helix_bringup fault_injector
# standalone benchmarks (no ROS 2 required)
python3 benchmark_helix.pypython3 analysis/extract_telemetry.py
python3 analysis/sweep.py # about 70 s
python3 analysis/idle_margin.py
python3 analysis/plot.py
python3 -m pytest tests/test_detector_sweep.py -qdocs/comparison.md is a package-by-package comparison
against diagnostic_updater / diagnostic_aggregator, ros-safety/software_watchdogs,
system_modes, Nav2 recovery behaviors, and twist_mux. It names the parts of
HELIX that plainly duplicate existing, better-maintained packages (its node
health topic re-does what diagnostic_aggregator already does; its original
heartbeat mechanism was a slower, chattier reimplementation of a DDS
liveliness lease), states where the closed-loop gap actually holds up, and
recommends against defaulting to the newer DDS-liveliness detection path
before it. The self-criticism is there because a repo that cannot say what it
duplicates cannot be trusted about what it does not.
| Tier | State | Validation |
|---|---|---|
Sense (helix_core, helix_adapter) |
stable | Hardware-validated across 8 GO2 and Jetson lab sessions (2026-04-03 to 2026-04-23). Detector operating point measured post hoc, see above; shipped config unchanged. |
Sense, C++ port (helix_sensing_cpp) |
work in progress | 30-min hardware parity run: -56% RSS, -60% CPU vs Python, though 44% RSS missed the 30% design-doc target. Launch-gated (use_cpp_anomaly=false). |
Context (helix_diagnosis.context_buffer) |
fixed, re-verify on hardware | Crashed roughly 1 s after activation in every prior session on an rclpy bytes/int detail. Fixed and unit-tested; not yet re-confirmed on a live GO2. |
Diagnose (helix_diagnosis) |
work in progress | Closed-loop validated on a live GO2 in Session 8, 14/14 hints correctly ruled. |
Recover (helix_recovery) |
work in progress | Validated end to end in Session 8: 14 hints consumed, allowlist and cooldown audited, 3,064 zero-twist commands published. Caveat: /helix/cmd_vel has 0 downstream subscribers, so STOP_AND_HOLD is currently a void publish, not yet wired to a twist_mux fallback. |
Explain (helix_explanation) |
work in progress | 26 unit tests green. Ships llm_enabled=false; Jetson llama-server deployment pending. |
Last stable release without the closed-loop stack:
v0.2.1. Current
self-healing work is tagged
v0.3.0-wip-self-healing.
| Package | Language | Tier | Contents |
|---|---|---|---|
helix_msgs |
msg | shared | FaultEvent, RecoveryHint, RecoveryAction, GetContext srv |
helix_core |
Python | Sense | anomaly_detector, heartbeat_monitor, log_parser (reference implementation) |
helix_sensing_cpp |
C++ | Sense | C++ port of anomaly_detector (RollingStats kernel + LifecycleNode component). Launch-gated; Python stays default until hardware parity is re-confirmed. |
helix_adapter |
Python | Sense | Lifecycle nodes bridging robot-specific telemetry (topic-rate monitor, JSON state parser, pose drift) to /helix/metrics |
helix_diagnosis |
Python | Context, Diagnose | context_buffer (rosout ring + metric/health snapshot), diagnosis_node (IDLE / STOP_AND_HOLD state machine), pure-function rules |
helix_recovery |
Python | Recover | recovery_node with SafetyEnvelope (enable, cooldown, allowlist). Only publisher of cmd_vel. |
helix_explanation |
Python | Explain | llm_explainer and llm_client: llama-server sidecar client, response_format: json_schema, ThreadPoolExecutor, deterministic fallback. Advisory only. |
helix_bringup |
Python | Ops | Launch files, YAML config, fault_injector |
Five benchmark suites evaluate the sensing components.
| Benchmark | Key Result | ROS 2? |
|---|---|---|
| Algorithmic throughput | ~81K samples/sec (PC i7-7700), ~64K (Jetson Orin NX) | No |
| End-to-end ROS 2 latency | 1.16 ms mean (p95: 1.24 ms) | Yes |
| Realistic anomaly detection | 96.5% TPR at Z=3.0 with marginal anomalies; 0% TPR for 3-sigma in Laplace noise | No |
| Log parser accuracy | 22/22 correct; ~777K msg/sec (PC), ~156K (Jetson Orin NX) | No |
| GO2 attachability | 1/4 HELIX inputs natively available; 54 topics adaptable | No |
| Adapter-based detection | 4 real FaultEvents from a live GO2 LiDAR rate anomaly | Yes |
Full results, methodology, and caveats: RESULTS.md. Known
limitations: docs/LIMITATIONS.md.
Unit tests exercise the helix_core nodes via rclpy in isolation. ROS 2
Humble is required.
cd ~/helix_ws
source /opt/ros/humble/setup.bash
colcon test --packages-select helix_core
colcon test-result --verboseFull details: TESTING.md.
Target platform: Unitree GO2 quadruped with an NVIDIA Jetson Orin NX 16 GB companion computer. The sensing and recovery logic is platform-independent; adapter nodes isolate the robot-specific telemetry.
Eight lab sessions (2026-04-03 to 2026-04-23) demonstrated:
- HELIX lifecycle nodes running persistently on the Jetson alongside the live GO2 stack
- A 30-minute persistent deployment with all success criteria green (Session 5)
- A 1-hour stability run with an RSS plateau, refuting earlier leak concerns (Session 7)
- IMU-excluded overhead: 6-node sum from 47.6% to 5.86% core CPU (-88%)
- Real
FaultEventdetection from LiDAR rate anomalies on the GO2 via the adapter - Ground-truth fault injection with ~1.8 s end-to-end detection latency
- Algorithmic benchmarks on the Jetson Orin NX (62-64K samples/sec)
- Session 8: end-to-end closed loop on a live GO2, 30 faults leading to 14 recovery hints (R1 STOP_AND_HOLD and R2 RESUME) leading to 14 audited actions (allowlist and cooldown), 3,064 zero-twist commands, and 9 STOP_AND_HOLD events in 7m19s on an idle robot; a 30-min C++ anomaly-detector parity run at -56% RSS and -60% CPU vs Python (RSS missed the 30% design target at 44%)
Full evidence, scope, and limitations: docs/GO2_HARDWARE_EVIDENCE.md.
HELIX ships as a public repo and demo video: a working self-healing system that other roboticists can install and adapt. Forward pillars:
- Close the recovery loop physically. Wire
/helix/cmd_velthrough atwist_muxfallback so STOP_AND_HOLD reaches the robot, not a void publish. This is the single biggest gap between "proven" and "true" above. - Ship the measured detector operating point. The shipped
zscore_threshold: 4.0, window_size: 60is measurably blind to a sustained fault (1/62 detection on a 10-sigma step);analysis/'s proposed3.5 / 120is not yet the default pending a hardware confirmation pass, particularly onrate_hz/utlidar_robot_odom, which is unmeasured on idle data today. - C/C++ on the hot paths. Python is a RAM and latency liability on the Jetson at steady state. The anomaly detector port has landed; the heartbeat monitor, log parser, and adapter rate-monitor follow. Target: under 30% of the Python RSS baseline.
- Local LLM for heal, flag, and predict. Qwen2.5-1.5B-Instruct Q4_K_M via
a llama-server sidecar on the Jetson (~1.5 to 1.7 GB RSS),
schema-constrained JSON output, advisory only. See
docs/LLAMA_SERVER_JETSON_SETUP.mdfor the Jetson deployment runbook.
